CCT TOWER Elite

A Reusable Universal 1600L Pallet Shipper solution for the global distribution of temperature sensitive products with a reliable duration of 120+ hours without manual intervention or Temperature Controlled Vehicle (TCV)
Request a Quote
Order

Universal Global Pharma Performance

  • Most light weight solution in the market: offering class-leading volumetric performance allowing 4 pallet per PMC and optimal payload volume.
  • Universal EU/US pallet footprint with 1639 L internal payload for large volume shipments.
  • 120-hour best-in-class thermal compliance for ranges: 2–8°C, 15–25°C, frozen (–25°C  to –15°C), and deep frozen (below –60°C). With different PCM plates or dry ice,
  • Robust performance – fully tested against ISTA 7D, ensuring proven reliability in real-world conditions.
  • Integrated IoT + BLE/cellular monitoring for real-time temperature visibility and asset tracking.
  • Sustainable: fully reusable and recyclable.
  • ASTM4169-tested protection ensuring product integrity throughout transit.

Universal Global Pharma Performance

  • Air-freight friendly, compatible with lower-deck cargo on wide-body aircraft.
  • No intervention required in transit, with easy double-door access for safe operation.
  • Global availability within 24 hours, with one-way lease
  • Low total cost of ownership, trusted globally across pharma supply chains.
  • Available through CCT's Rental Program for a flexible and efficient ready-to-use solution
Key Features
Overview
Recommended Use
Specs
Documentation

Overview

The CCT TOWER Elite Reusable Universal 1600L pallet shipper is designed to meets the highest standards for temperature-controlled pharmaceutical logistics, offering unique pack-out options for a variety of pallet sized insulated shipping needs.

It ensures safe and simple transportation of temperature sensitive pharmaceutical products across four temperature ranges: 2–8°C, 15–25°C, frozen (–25 to –15°C), and deep frozen (below –60°C). With different PCM plates or dry ice, it provides over 120 hours of product protection—making it ideal for extended pallet shipment logistics

CCT Tower pallet systems are hibernation capable, meaning that in the right storage environment, they can go above the standard 120 hours protection to accommodate scheduled or unscheduled shipment delays without compromising product safety.

The CCT TOWER Elite 1600L shipper incorporates an integrated BLE/cellular Bluetooth data logger (compliant with RTCA DO 160G Part 21 H) along with a visible data display. It’s built to support a wide range of data logging and IoT systems already used in pallet solutions across global supply chains.

Key Features

20 container icon in purple transparent background-1

20" Container

Fits 8
40 container icon purple transparent background no number-1

40” container

Fits 16
temperature controlled truck icon purple transparent background

TCV

Fits 8
articulated lorry icon purple transparent background

Articulated Lorry

Fits 8
airplane icon purple transparent background

Airline pallet

4 per PMC
pallet icon purple transparent background-1

Pallet Size

EU/US Pallets
tare weight icon purple transparent background

System Tare weight

370kg/815lbs
volumetric weight icon purple no backgound no text

Volumetric weight

450kg/992lbs
show product going into pallet shipper on the side icon dark purple transparent background-1

Internal Payload

1640 Litres

Suitable for the transportation of Life Science Products

The CCT TOWER Elite pallet shipper is ideally suited for the transportation of Life Science Products such as:

  • Vaccines (including Covid 19 and ABIs)
  • Biotech products (Oncology, cardiovascular, etc)
  • Insulins
  • Active Pharmaceutical Ingredients (API)
  • Drug Substance
  • Semi-Finished and Finished products
  • Any other product requiring a stable temperature environment for transportation

Specs

Imperial Metric
Specifications
Model Number
Duration
Temperature Range
Size
Payload Dimensions: (Inches) (Millimeters) (Centimeters)
Height
Length
Width
External Dimensions: (Inches) (Millimeters) (Centimeters)
Height
Length
Width
Payload Volume
(Liters)
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT Tower Elite R
Duration
120+ HRS
Temperature Range
RFG (+2 to +8C)
Size
1640 L
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
51.18 1300
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.4 1230
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
10.39 1026
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.99 1600
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
56.69 1440
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
46.06 1170
Payload Volume
(Liters)
1640
Tare Weight
(Pounds)
(Kilograms)
370 370 KG
Valumetric Weight
(Pounds)
(Kilograms)
450 450 KG
Model Number
CCT Tower Elite F
Duration
120+ HRS
Temperature Range
FRZ (-25 to -15C)
Size
1640 L
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
51.18 1300
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.4 1230
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
10.39 1026
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.99 1600
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
56.69 1440
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
46.06 1170
Payload Volume
(Liters)
1640
Tare Weight
(Pounds)
(Kilograms)
405 405 KG
Valumetric Weight
(Pounds)
(Kilograms)
450 450 KG
Model Number
CCT Tower Elite D
Duration
120+ HRS
Temperature Range
DI (-60 to -20C)
Size
1640 L
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
51.18 1300
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.4 1230
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
10.39 1026
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.99 1600
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
56.69 1440
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
46.06 1170
Payload Volume
(Liters)
1640
Tare Weight
(Pounds)
(Kilograms)
430 430 KG
Valumetric Weight
(Pounds)
(Kilograms)
450 450 KG

Documentation

create a dark purple brochure icon-1

Brochure

Download

docs

create a dark purple fact sheet icon

Data Sheet

Download
create a dark purple fact sheet icon

Qualification Report

Contact Us to request the qualification reports

Get additional product information

Please provide any additional information about your temperature sensitive shipping requirements so that we can best address your needs.



NOTE: Products are not always available in every region. Please contact us for more detail.
