CCT Edge™ Plus

with PCM-Based Refrigerants

With over 50 years of experience in the cold chain sector, our next-generation single use pallet solutions using PCM-based refrigerants are ready to meet your different temperature requirements to ship bulk / palletized shipments.

  • Universal configuration (all year pack out).
  • When placed into a +2°C to +8°C environment these
    shippers go into hibernation, thereby extending the
    duration of coverage and protection to the payload from
    thermal excursions.
  • Consistent drug stability for 96+ hours of thermal
    protection for +2°C to +8°C and +15°C to +25°C products.
  • Qualified to ISTA 7E, Australian Summer/Winter (ASW), International ISTA/INT standards, and customs profiles (qualification data available upon request).
  • Available in 17 different payloads - from 235L up to 3040L.
  • Single and Double pallet options
  • Suitable for air freight transport and offering a range of size options.
  • Flat-packed delivery is available in the larger size ranges
    for cost-effective shipping.
  • Universal configuration (all year pack out).
  • When placed into a +2°C to +8°C environment these
    shippers go into hibernation, thereby extending the
    duration of coverage and protection to the payload from
    thermal excursions.
  • Consistent drug stability for 96+ hours of thermal
    protection for +2°C to +8°C and +15°C to +25°C products.
  • Qualified to ISTA 7E, Australian Summer/Winter (ASW), International ISTA/INT standards, and customs profiles (qualification data available upon request).
  • Available in 17 different payloads - from 235L up to 3040L.
  • Single and Double pallet options
  • Suitable for air freight transport and offering a range of size options.
  • Flat-packed delivery is available in the larger size ranges
    for cost-effective shipping.
  • Universal configuration (all year pack out).
  • When placed into a +2°C to +8°C environment these
    shippers go into hibernation, thereby extending the
    duration of coverage and protection to the payload from
    thermal excursions.
  • Consistent drug stability for 96+ hours of thermal
    protection for +2°C to +8°C and +15°C to +25°C products.
  • Qualified to ISTA 7E, Australian Summer/Winter (ASW), International ISTA/INT standards, and customs profiles (qualification data available upon request).
  • Available in 17 different payloads - from 235L up to 3040L.
  • Single and Double pallet options
  • Suitable for air freight transport and offering a range of size options.
  • Flat-packed delivery is available in the larger size ranges
    for cost-effective shipping.

Overview

The CCT Edge™ Plus are engineered for the most demanding large‑scale pharmaceutical logistics. From vaccines and biologics to diagnostics and clinical trial materials, it safeguards bulk palletized loads with exceptional thermal stability.

Purpose‑built for global distribution, the CCT Edge™ Plus deliver reliable, long‑duration protection that ensures product integrity every step of the journey.

Engineered with multi-layered insulation like vacuum-insulated panels, polyurethane foam, and phase-change materials, they shield against temperature excursions from extreme weather, delayed multi-leg routes, or infrastructure-limited areas, ensuring every dose arrives potent, stable, and GDP-compliant.



Key Features

deep purple global icon

Global Pallet Compatibility

Designed for Euro, USA, and AU pallet footprints
noun-product-4679125

Efficient Handling & Deployment

Delivered Ready to Use and Flat‑packed for reduced storage and transport costs
noun-thermal-2793822

Proven Thermal Performance

72‑ to 144‑hour qualified thermal protection
show product going into pallet shipper on the side icon dark purple transparent background-1

Versatile Loading & Temperature Formats

Available in both front‑loading and top‑loading designs and multiple temperatures.
volumetric weight icon purple no backgound no text

Flexible Payload Capacity

Suitable for small batch shipments through to full pallet loads.
noun-product-4679125

Advanced Insulation Options

EPS, XPS, PU, and VIP insulation configurations.

Recommended Use

Cold chain technologies are essential for safeguarding temperature-sensitive products during transit under challenging conditions like extreme weather and complex routes. These solutions ensure product integrity for critical sectors including pharmaceuticals and biologics, particularly in infrastructure-limited regions.

Extreme Weather Conditions
Extreme heat, cold, floods, or storms can cause temperature excursions that compromise product efficacy. Robust packaging with phase-change materials (PCMs) and real-time GPS-enabled monitoring maintain stability despite unpredictable climates.

Multi-Leg or Delayed Transit Routes
Shipments involving multiple transport modes or delays face prolonged exposure risks, amplifying spoilage potential. Optimized routing, hybrid fleets (air/road), and predictive analytics minimize dwell times and ensure compliance across legs.​



Pharmaceuticals, Diagnostics, and Vaccines
These items require precise ranges like 2-8°C to preserve potency, with vaccines and diagnostics highly vulnerable to deviations. Validated insulated containers and continuous data loggers support regulatory standards like GDP.

Clinical Trial Shipments
Time-critical biologics in trials demand uninterrupted chains to avoid data invalidation. Dedicated or hybrid fleets with sensor integration handle oncology/immunology needs, especially in multi-regional studies.​

Biologics and Specialty Chemicals
Highly sensitive to fluctuations, these require thermal protection prevent denaturation.

Routes with Limited Infrastructure
Remote or emerging APAC areas lack reliable cold storage, heightening risks. Portable cooling solutions, air freight, and vendor coordination enable resilient supply chains for pharma/logistics needs.

Specs

Imperial Metric
Specifications
Model Number
Duration
Temperature Range
Size
Payload Dimensions: (Inches) (Millimeters) (Centimeters)
Height
Length
Width
External Dimensions: (Inches) (Millimeters) (Centimeters)
Height
Length
Width
Flat Pack Dimensions: (Inches) (Millimeters) (Centimeters)
Height
Length
Width
Payload Volume
(Liters)
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
465-6196P-RFG
Duration
96 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
20.87 530
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.47 901
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
19.41 493
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
38.19 970
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
47.24 1200
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
31.50 800
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
235.4
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
465-6396P-CRT
Duration
96 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
20.87 530
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.47 901
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
19.41 493
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
38.19 970
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
47.24 1200
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
31.50 800
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
235.4
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
466-6196P-RFG
Duration
96 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
27.09 688
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.47 901
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
27.28 693
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
44.65 1134
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
47.24 1200
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
39.37 1000
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
429.6
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
466-6396P-CRT
Duration
96 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
27.09 688
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.47 901
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
27.28 693
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
44.65 1134
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
47.24 1200
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
39.37 1000
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
429.6
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
747-6196P-RFG
Duration
96 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
42.17 1071
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.28 896
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
27.28 693
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
59.61 1514
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
47.24 1200
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
39.37 1000
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
32.28 820
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
47.64 1210
Payload Volume
(Liters)
665.0
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
747-6396P-CRT
Duration
96 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
42.17 1071
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.28 896
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
27.28 693
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
59.61 1514
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
47.24 1200
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
39.37 1000
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
32.28 820
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
47.64 1210
Payload Volume
(Liters)
665.0
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
314-61120P-RFG
Duration
96 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
45.31 1151
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
33.07 840
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.48 1587
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.38 1559
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
45.83 1164
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
38.43 976
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.61 1565
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
53.94 1370
Payload Volume
(Liters)
1198.9
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
314-63120P-CRT
Duration
96 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
45.31 1151
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
33.07 840
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.48 1587
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.38 1559
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
45.83 1164
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
38.43 976
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.61 1565
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
53.94 1370
Payload Volume
(Liters)
1198.9
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
313-61120P-RFG
Duration
96 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
45.31 1151
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
40.55 1030
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
39.37 1000
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.81 1570
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
54.92 1395
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
39.37 1000
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.81 1570
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
54.92 1395
Payload Volume
(Liters)
1470.1
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
313-63120P-CRT
Duration
96 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
45.31 1151
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
40.55 1030
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
39.37 1000
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.81 1570
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
54.92 1395
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
39.37 1000
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
61.81 1570
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
54.92 1395
Payload Volume
(Liters)
1470.1
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-3820-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.24 1200
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
81.10 2060
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
91.54 2325
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
3040.6
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-3820-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.24 1200
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
81.10 2060
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
91.54 2325
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
3040.6
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-3100-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.24 1200
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
65.35 1660
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
75.79 1925
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
2450.2
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-3100-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Double Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.24 1200
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
65.35 1660
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
75.79 1925
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
2450.2
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-2540-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Double half pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
81.10 2060
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.85 1190
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
91.54 2325
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1900.4
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-2540-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Double half pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
81.10 2060
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.85 1190
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
91.54 2325
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1900.4
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-2070-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Double half pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
65.35 1660
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.85 1190
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
75.79 1925
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1531.4
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-2070-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Double half pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
65.35 1660
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
48.43 1230
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.85 1190
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
75.79 1925
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
58.86 1495
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1531.4
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-2000-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.64 1210
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.43 1230
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
40.55 1030
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
58.86 1495
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
50.98 1295
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1532.9
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-2000-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.64 1210
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.43 1230
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
40.55 1030
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
58.86 1495
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
50.98 1295
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1532.9
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-1660-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.64 1210
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
32.68 830
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
59.25 1505
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
43.11 1095
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1245.3
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-1660-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Single pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
47.64 1210
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
32.68 830
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
62.20 1580
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
59.25 1505
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
43.11 1095
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
1245.3
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-1325-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Half Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.43 1230
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
40.55 1030
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.46 1180
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
58.86 1495
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
50.98 1295
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
950.2
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-1325-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Half Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.43 1230
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
40.55 1030
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.46 1180
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
58.86 1495
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
50.98 1295
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
950.2
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-1095-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Half Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
32.68 830
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.46 1180
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
59.25 1505
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
43.11 1095
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
771.9
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-1095-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Half Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
48.82 1240
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
32.68 830
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.46 1180
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
59.25 1505
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
43.11 1095
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
771.9
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-950-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
43.31 1100
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
31.50 800
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.46 1180
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
53.74 1365
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
41.93 1065
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
660.0
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-950-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
29.53 750
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
43.31 1100
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
31.50 800
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
46.46 1180
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
53.74 1365
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
41.93 1065
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
660.0
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-750-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
24.61 625
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
39.37 1000
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
31.50 800
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
41.54 1055
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
49.80 1265
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
42.32 1075
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
500.0
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-750-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
24.61 625
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
39.37 1000
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
31.50 800
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
41.54 1055
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
49.80 1265
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
42.32 1075
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
500.0
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-560-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
22.05 560
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.43 900
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
27.56 700
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
38.98 990
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
45.87 1165
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
38.39 975
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
352.8
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-560-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
22.05 560
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
35.43 900
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
27.56 700
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
38.98 990
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
45.87 1165
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
38.39 975
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
352.8
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-425-CRT
Duration
120 HRS
Temperature Range
CRT (15°C to 25°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
18.11 460
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
31.50 800
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
26.77 680
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
35.04 890
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
42.32 1075
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
37.60 955
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
250.2
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)
Model Number
CCT-425-RFG
Duration
120 HRS
Temperature Range
RFG (2°C to 8°C)
Size
Sub Pallet
Payload Dimensions: Height (Inches) (Millimeters) (Centimeters)
18.11 460
Payload Dimensions: Length (Inches) (Millimeters) (Centimeters)
31.50 800
Payload Dimensions: Width (Inches) (Millimeters) (Centimeters)
26.77 680
External Dimensions: Height (Inches) (Millimeters) (Centimeters)
35.04 890
External Dimensions: Length (Inches) (Millimeters) (Centimeters)
42.32 1075
External Dimensions: Width (Inches) (Millimeters) (Centimeters)
37.60 955
Flat Pack Dimensions: Height (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Length (Inches) (Millimeters) (Centimeters)
Flat Pack Dimensions: Width (Inches) (Millimeters) (Centimeters)
Payload Volume
(Liters)
250.2
Tare Weight
(Pounds)
(Kilograms)
Volumetric Weight
(Pounds)
(Kilograms)

Documentation

create a dark purple brochure icon-1

Brochure

Download



create a dark purple fact sheet icon

Data Sheet

Download
create a dark purple fact sheet icon

Qualification Report

Contact Us to request the qualification reports

Key Features

         Specifications

Edge-PCM_Specs



Get additional product information

Please provide any additional information about your temperature sensitive shipping requirements so that we can best address your needs.



NOTE: Products are not always available in every region. Please contact us for more detail.

Contact Us

Contact Info

CCT Global Headquarters
135 Constitution Boulevard
Franklin, Massachusetts 02038
+1 (800) 370-8566

More Info

Search

    Copyright © 2026 Cold Chain Technologies
    ```html
